DESCRIPTION
- Drawn ice, compact and durable
- Reduced consumption (1lt water/1kg ice, air vers.)
- Electromechanical operation system
- External structure AISI 304, Scotch Brite finish
- Evaporator AISI 304, screw AISI 303
- Air or water condensation
- Standard voltage and special voltages
- Insulated door, concealed opening
- ON-OFF switch
- Water basin, dustproof system
- Automatic water loading
- Simplified cleaning thanks to rounded surfaces
- Protective external filter, removable, easy to clean
- HCFC-free internal container insulation
- Tropical Class Model +43°C
- RoHS Directive Compliance
- Under counter model
Fields of use:
Technical information
| Production in 24h |
90 kg |
| Tank capacity |
20 kg |
| Approximate dimensions of granules |
8 x 16 x 7 mm |
| Condensation |
Air - Water |
| Refrigerant |
R290 |
| Standard voltage |
220-240V~ 50Hz |
| Electricity consumption |
440W |
| Fuse |
10 A |
| Water consumption |
Air condensation: 1 l/kg
Water condensation: 7 l/kg |
| Dimensions |
L.50 x D.66 x H.69 cm |
| Net weight gross weight |
59/67 kg |
| Finish |
AISI 304 (18/8) scotch brite stainless steel |
Installation conditions
| Room temperature |
+10 / +43 °C |
| Water temperature |
+3 / +32 °C |
| Voltage |
± 10% |
| Incoming water pressure |
1bar (14psi) / 6bar (84psi) |
| Installation |
Internal |
The technical data refers to the following conditions
| Room temperature |
+21°C |
| Water temperature |
+15°C |
| Electricity consumption |
+43°C (standard voltage) |
| Dimensions without feet |
Connections
| 1 Water inlet |
99mm - 158mm - 3/4" |
| 2 Water drain |
48mm - 151mm - 24mm |
| 3 Electrical connection |
87mm - 23mm |
THE MANUFACTURER recommends using a water filter or softener. Reducing or eliminating calcium from your water can greatly improve the life and efficiency of your equipment by preventing the build-up of calcium in kettles, hot water coils and taps. It also prevents the formation of white marks on glasses and plates. Damage caused by limescale is not covered by the warranty.
