ACTIVATED CARBON CONTROL UNIT
ACTIVATED CARBON CONTROL UNIT

Carbon filter unit

RF_03088_50772
Can be ordered with the following maximum capacities: - 1400 m³/h - 2500 m³/h
899,14 €

Select options

Available Options : ECO 14 - Portata massima: 1400 m³/h
Quantity

Ask a Quote

Secure payments, including interest-free instalments

Cards Cards and PayPal
PayPal Pay in 3 instalments
Alma Pay in instalments

Characteristics:
-Aluminium tubular structure
- Double paneling in AISI 304 stainless steel, removable and complete with gasket
- Internal insulation and soundproofing in expanded polyurethane
- 4.8 cm thick pleated synthetic filters with 85% gravimetric efficiency (G3) - EN 779 class
- E207 type activated carbon filters


Activated carbon control unit suitable for systems with electrically powered products.

Limitations of use:
Max. temperature fluid transported: +60°
Max. humidity: 80% RH
Assembly: internal

DATASHEET

ECHO 14

Dimensions: L.70 x D.40 x H.70 cm
Maximum flow rate: 1400 m³/h
Hst: 150 Pa
Number of filters: 5


ECO 25

Dimensions: L.70 x D.70 x H.70 cm
Maximum flow rate: 2500 m³/h
Hst: 150 Pa
Number of filters: 9

RF_03088_50772

Data sheet

Dimensions (LxDxH cm)
70 x 40 x 70
70 x 70 x 70
Porta (m³/h)
1400
2500
No. filters
5
9
