Conceived with particular attention aimed at
ease of installation and
optimization of the cleaning system , guaranteed by easy access to the internal parts. The products on display are always kept at an
ideal temperature , thanks to the flow of refrigerated air and a
well-sized refrigeration system . It is a product with
low energy consumption and
low environmental impact : the tub is made
without the use of CFCs . All phases, from design to production, have been taken care of in detail: technology and design
made in Italy .
CHARACTERISTICS :
• Compact but with a large display surface
• Suitable for small, medium and large distribution
• “Made in Italy” technology, design and production
• Easy installation
• Optimization of the cleaning system
• Low energy consumption
• Low environmental impact
• Bathtub made without the use of CFCs
• Ventilated refrigeration
• Possibility of customizations on request
STANDARD EQUIPMENT :
• Thermoformed and insulated sides (4 cm thick each) with tempered glass side
• Electronic control panel
• Defrost at stop
• Upper lighting with neon lamp
• 4 shelves in non-toxic white post-painted sheet metal or in stainless steel (for stainless steel version), adjustable in height, equipped with price holder, without lighting, without product holding grids
• R452A valve in both the version with group and without group
AVAILABLE VERSIONS :
• With built-in unit (equipped with automatic condensation water recovery and evaporation system, via stainless steel coil)
• With connection to remote compressor: on request
• Meat version (C): on request
• Stainless steel version: on request
AVAILABLE COLORS :
INSERT IN THE NOTES , WHILE CONFIRMING THE ORDER, THE COLOR OF THE SHOWCASE YOU PREFER FROM THE POSSIBILITIES LISTED ABOVE. IF YOU DON'T CHOOSE A COLOR WE WILL DELIVER TO YOU THE FIRST AVAILABLE SHOWCASE.
DATASHEET
VOLCANO 60
Dimensions : L.68 x D.60 x H.197 cm
Lower shelf depth : 40 cm
Shelves Depth : 26 cm
Exhibition surface area : 0.93 m2
Temperature : +3/+5 °C
Total Power Absorption : 1467 W (Ventilated display with built-in group) - 44 W (Ventilated display with remote group)
Power Absorbed by Lighting : 1 x 18 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Capacity for Remote Group (Evap. T. -10°C) : 660 W
Gross Weight : 100 kg
VOLCANO 80
Dimensions : L.88 x D.60 x H.197 cm
Lower shelf depth : 40 cm
Shelves Depth : 26 cm
Exhibition surface area : 1.25 m2
Temperature : +3/+5 °C
Total Power Absorption : 1485 W (Ventilated display with built-in group) - 55 W (Ventilated display with remote group)
Power Absorbed by Lighting : 1 x 36 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Capacity for Remote Group (Evap. T. -10°C) : 880 W
Gross Weight : 120 kg
VOLCANO 100
Dimensions : L.108 x D.60 x H.197 cm
Lower shelf depth : 40 cm
Shelves Depth : 26 cm
Exhibition surface area : 1.57 m2
Temperature : +3/+5 °C
Total Power Absorption : 1595 W (Ventilated display with built-in group) - 84 W (Ventilated display with remote group)
Power Absorbed by Lighting : 1 x 36 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Capacity for Remote Group (Evap. T. -10°C) : 1100 W
Gross Weight : 140 kg
VOLCANO 125
Dimensions : L.133 x D.60 x H.197 cm
Lower shelf depth : 40 cm
Shelves Depth : 26 cm
Exhibition surface area : 1.95 m2
Temperature : +3/+5 °C
Total Power Absorption : 1595 W (Ventilated display with built-in group) - 84 W (Ventilated display with remote group)
Power Absorbed by Lighting : 1 x 36 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Capacity for Remote Group (Evap. T. -10°C) : 1375 W
Gross Weight : 170 kg
VOLCANO 140
Dimensions : L.148 x D.60 x H.197 cm
Lower shelf depth : 40 cm
Shelves Depth : 26 cm
Exhibition surface area : 2.19 m2
Temperature : +3/+5 °C
Total Power Absorption : 1595 W (Ventilated display with built-in group) - 84 W (Ventilated display with remote group)
Power Absorbed by Lighting : 1 x 58 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Capacity for Remote Group (Evap. T. -10°C) : 1540 W
Gross Weight : 200 kg
VOLCANO 150
Dimensions : L.158 x D.60 x H.197 cm
Lower shelf depth : 40 cm
Shelves Depth : 26 cm
Exhibition surface area : 2.35 m2
Temperature : +3/+5 °C
Total Power Absorption : 1595 W (Ventilated display with built-in group) - 84 W (Ventilated display with remote group)
Power Absorbed by Lighting : 1 x 58 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Capacity for Remote Group (Evap. T. -10°C) : 1650 W
Gross Weight : 225 kg
VOLCANO 187
Dimensions : L.195.5 x D.60 x H.197 cm
Lower shelf depth : 40 cm
Shelves Depth : 26 cm
Exhibition surface area : 2.94 m2
Temperature : +3/+5 °C
Total Power Absorption : 2660 W (Ventilated display with built-in group) - 129 W (Ventilated display with remote group)
Power Absorbed by Lighting : 1 x 58 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Capacity for Remote Group (Evap. T. -10°C) : 1980 W
Gross Weight : 255 kg
FOR THIS PRODUCT AND FOR ALL SALINA - VULCANO - KIBUK PRODUCTS WE SUGGEST ORDERING THE NECESSARY CAGE TO ENSURE SAFE TRANSPORT.
