DIMENSIONS: 704x962x 1904 h

SQUARE BASKET MEASURES: 500x500 mm

ELECTRICAL POWER SUPPLY: 3x230 - 400V+N / 50 Hz

WASHING PUMP POWER: 0.75 kW (HP 1)

WASHING PUMP CAPACITY: 420 lt/min

BOILER RESISTANCE: W 6000

TANK RESISTANCE: W 4500

MAXIMUM ABSORBED POWER: W 6750

TANK CAPACITY: 55 litres

BOILER CAPACITY: lt. 9

WASH/RINSE TEMPERATURE: 55°/85°

CYCLE DURATION: 60/120 sec.

CYCLES HOUR: 60/30

SUPPLY PRESSURE: bar 2:4

Ø LOADING/DRAIN HOSE (INTERNAL Ø): 3/4" / 31

FEED WATER: Max 50°C

NOISE LEVEL: < 62 dBA

HOURLY PRODUCTION (GLASSES): 3000:1500

HOURLY PRODUCTION (DISHES): 1080:540

NET WEIGHT: 105 kg

THE MANUFACTURER recommends the use of a filter or a water softener device. Reducing or eliminating calcium from water can significantly improve the life and efficiency of your machinery by preventing calcium build-up in kettles, hot water coils and taps. It also prevents the formation of white marks on glasses and plates. Any damage caused by limescale deposits is not covered by the warranty
